Product Description
RETICLE
Proprietary Leupold Design
Based off the T-MOA reticle
Provided hash-marks in 1 MOA increments
Features 10 MOA of measurment in each direction
5 MOA hash is wider for quick reference
Upper portion is left open for easier spotting
Non-caliber specific
The VX®-Freedom® 4-12x40mm delivers legendary Leupold® performance and dependability in a versatile magnification range that’s ideal for mid to longer-range shots. It’s also equipped with the Leupold® Custom Dial System® (CDS), which gives you a customizable ballistics solution at your fingertips. This system is easy to install and even easier to use.
Built around Leupold's Advanced Optical System, the VX-Freedom delivers tried and true light transmission, best in class glare reduction in harsh light, and the resolution and clarity that recreational sportsmen and sportswomen demand.
The VX-Freedom is 100% waterproof and fogproof, and guaranteed to get the job done every time. And like all Leupold riflescopes, it's designed, machined, and assembled in the USA and guaranteed for life.
SPECIFICATIONS
FinishMatte
Adjustable ObjectiveNo
Side FocusNo
Reticle Focal PlaneSecond Focal Plane
Elevation Adjustment TypeCDS
Locking DialNo
Zero Lock DialNo
Revolution IndicatorNo
Rezero TypeSet Screw
Windage Adjustment TypeFinger Click
Custom Dial System (CDS)Yes
BDC Dial IncludedNo
Reticle TypeSecond Focal Plane
ReticleDuplex
Magnification TypeVariable
IlluminatedNo
Nightvision Compatible IlluminationNo
Daylight Bright IlluminationNo
Motion Sensor Technology (MST)No
Electronic Reticle LevelNo
Guard-ion Lens CoatingNo
Weight (oz)13.1
Elevation Adjustment Value per Click1/4MOA
Elevation Adjustment Range (MOA)80
Elevation Adjustment Range (MIL)23
Elevation Adjustment Range (cm @ 100m)233
Elevation Adjustment Per Revolution15 MOA
Elevation Dial Travel Limit14MOA
Windage Adjustment Value per Click1/4MOA
Windage Adjustment Range (MOA)80
Windage Adjustment Range (MIL)23
Windage Adjustment Range (cm @ 100m)233
Windage Adjustment Per Revolution15 MOA
Magnification Max12
Magnification Min4
Objective Lens Diameter (mm)40
Linear FOV Low Mag (ft@100yds)21.5
Linear FOV High Mag (ft@100yds)10
Angular FOV Low Mag (Degrees)4.1
Angular FOV High Mag (Degrees)1.9
Eye Relief Low Mag (in)4.9
Eye Relief High Mag (in)3.7
Fixed Parallax-Free Distance (yd)150
