Product Description
BOLT series is an infrared scope for outdoor hunting. Designed based on infrared thermal imaging principles, it requires no external light sources during the day and at night, in all hard weather conditions (such as rain, snow, fog, and haze). It can be used without being affected by strong light and to observe even targets behind obstacles (such as branches, grass, and shrubs).BOLT series has a variety of battery-powered solutions with long operating hours, and can be widely used for hunting, observation and positioning in low visibility conditions
• NETD ≤20mK
• 50Hz high frame rate
• Built-in LRF
• Ballistic Calculation
• Recoil Activated Video function
• Gallery function
• Dual power supply system
• Built-in memory, supporting photographing, video recording
• Built-in Wi-Fi module, supporting APP connection
• Replaceable and rechargeable 18650 battery
• Ultra clear mode
• Pixel defect correction
- BOLT series Thermal Imaging Scope
- Heated target for zeroing
- Portable bag
- 18650 Battery (x2)
- Data cable
- Lens cleaning cloth
- Quick start guide
- 18650 Battery charger
The Vision+ system offers top-notch thermal imaging and a stunning visual experience for users.
With its advanced sensor technology and innovative design, it captures temperature differences with incredible accuracy, delivering clear thermal images. The high-resolution AMOLED screen enhances color and contrast, providing an immersive viewing experience while being energy-efficient. The long eye relief design ensures comfort, allowing users to see the entire display without strain. Plus, the unique round screen mimics natural vision, reducing eye fatigue and helping users focus better.
Feature | Specification |
---|---|
Model | BOLT L35R |
Sensor Resolution | 384 × 288 |
Pixel Size | 12μm |
NETD | ≤20 mK |
Frame Rate | 50 Hz |
Objective Lens | 35mm F1.0 |
Field of View (°) | 7.5 × 5.7 |
Magnification (×) | 3.5 ~ 14 |
Detection Range (m) | 1800 |
Eye Relief (mm) | 50 |
Diopter Adjustment (D) | -5 ~ +5 |
Display | AMOLED 1024 × 768 |
Battery Type | Built-in 5,000 mAh + Replaceable 18650 |
Max Operation Time (h) | 12 (at 22℃) |
Microphone | Supported |
Memory Capacity (GB) | 32 |
IP Rating | IP67 |
Operating Temp (℃) | -20 ~ +50 |
Weight (with battery) | 880 g |
Dimensions (mm) | 376 × 92 × 75 |
